| Quantity: | |
|---|---|
Self-Starting Diesel Generator
Fixed
Four Stroke
Water Cooling
AC Three Phase
Speed
BS-C394
Land Use
Common Units, Standby Unit, Emergency Crew
Low Noise
AC Rotating Exciter
Stamford
Smartgen, Deepsea...
Electric Start
315kw
Optional
as Per Request
60Hz
Packed in Plywood Cases or Wooden Cases or Foam, E
As for power
BOSSPOWER
China
85021200
100 Sets / Month
US$ 24000/Piece 1 Piece(Min.Order) | Request Sample
| PRODUCT DESCRIPTION |
| Frequency: 50HZ;Rotating speed: 1500Rpm | |||||
| Model | Power(KW) | Capacity(KVA) | Rated current(A) | Engine Model | Copy Stamford Type |
| BS-C25 | 20 | 25 | 36 | 4B3.9-G1 | BS184F |
| BS-C40 | 32 | 40 | 57.7 | 4BT3.9-G2 | BS184J |
| BS-C70 | 56 | 70 | 101 | 4BTA3.9-G11 | BS224G |
| BS-C85 | 68 | 85 | 122.7 | 6BT5.9-G1 | BS224G |
| BS-C120 | 96 | 120 | 173.2 | 6BTA5.9-G2 | BS274D |
| BS-C140 | 112 | 140 | 202 | 6BTAA5.9-G2 | BS274E |
| BS-C160 | 128 | 160 | 230.9 | 6CTA8.3-G1 | BS274F |
| BS-C275 | 220 | 275 | 396.9 | NTA855-G1A | BS314D |
| BS-C350 | 280 | 350 | 505 | NTA855-G2A | BS314E |
| BS-C400 | 320 | 400 | 577.4 | NTAA855-G7A | BS354C |
| BS-C450 | 360 | 450 | 649.5 | KTA19-G3 | BS354C |
| BS-C500 | 400 | 500 | 721.7 | KTA19-G4 | BS354D |
| BS-C600 | 480 | 600 | 866 | KTAA19-G6 | BS354E |
| BS-C750 | 600 | 750 | 1082.6 | KTA38-G2 | BS404B |
| BS-C800 | 640 | 800 | 1154.7 | KTA38-G2B | BS404C |
| BS-C900 | 720 | 900 | 1299 | KTA38-G2A | BS404D |
| BS-C800 | 800 | 1000 | 1443.4 | KTA38-G5 | BS404E |
| BS-C1250 | 1000 | 1250 | 1804.3 | KTA50-G3 | BS404G |
| Frequency: 60HZ;Rotating speed: 1800Rpm | |||||
| Model | Power(KW) | Capacity(KVA) | Rated current(A) | Engine Model | Copy Stamford Type |
| BS-C29 | 23 | 29 | 41.5 | 4B3.9-G1 | 184E |
| BS-C43 | 34 | 43 | 61.3 | 4BT3.9-G1 | 184H |
| BS-C63 | 50 | 63 | 90.2 | 4BTA3.9-G2 | 224D |
| BS-C80 | 64 | 80 | 115.5 | 4BTA3.9-G11 | 224F |
| BS-C94 | 75 | 94 | 135.3 | 6BT5.9-G2 | 224G |
| BS-C125 | 100 | 125 | 180.4 | 6BTA5.9-G2 | 274D |
| BS-C150 | 120 | 150 | 216.5 | 6BTAA5.9-G2 | 274E |
| BS-C188 | 150 | 188 | 270.6 | 6CTA8.3-G2 | 274F |
| BS-C250 | 200 | 250 | 360.9 | NT855-GA | 274J |
| BS-C394 | 315 | 394 | 568.3 | NTA855-G3 | 314E |
| BS-C438 | 350 | 438 | 631.5 | KTA19-G2 | 314F |
| BS-C513 | 410 | 513 | 739.8 | KTA19-G3 | 354C |
| BS-C625 | 500 | 625 | 902 | KTAA19-G5 | 354D |
| BS-C688 | 550 | 688 | 992.3 | KTAA19-G6A | 354E |
| BS-C775 | 620 | 775 | 1118.6 | KT38-G | 354F |
| BS-C906 | 725 | 906 | 1308 | KT38-G2 | 404C |
| BS-C1000 | 800 | 1000 | 1443.4 | KT38-G2A | 404D |
| Genset Model: | BS-C394 | ||
| Prime Power (kw/kva) | 315 / 394 | Standby Power(kw/kva) | 346.5 / 433 |
| Voltage (v) | 440 | Rated Speed (rpm) | 1800 |
| Frequency (Hz) | 60 | Rated Current (A) | 517 |
| Connection: | 3 phase 4 wire | Power Factor: | 0.8 |
| Engine Model: | NTA855-G3 | Alternator Model: | HCI444ES |
| Net Weight (kgs)-Open | 3060 | Net Weight (kgs)-Silent | 3900 |
| Dimensions (mm)-Open | 2950*1100*1600 | Dimensions (mm)-Silent | 3800X1200X1800 |
| Engine Parameter: | |
| Manufacturer/Model: Aspiration: Fuel System: Cylinder numbers Displacement: Bore x Stroke Compression Ratio: Max. Power: Governing System: | CCEC, C mmins, NTA855-G3 Turbocharged. after cooling PT Fuel Pump, EFC 6 cylinders in line, "L" type 14 L 140 x 152 mm 14.0 : 1 399KW / 533HP Electronic |
| Exhaust System | |
| Exhaust Volume: Exhaust temperature: Max. Allowed Back Pressure: | 1506 L/s 527 ºC 10 KPa |
| Intake System | |
| Max. Allowed Pressure: Burning Capacity: Air Flow: | 6.22 kPa 463 L/s 375 L/s |
| Fuel System | |
| 100% Load (Prime): 75% Load(Prime): 50% Load (Prime): | 71.4 L/h 54.3 L/h 38.2 L/h |
| Lube System | |
| Oil Capacity: Oil Consumption: Bottom shell oil capacity: Oil Pressure at rated speed: | 36.0 L ≤0.24L/h 36 L 241-345 kPa |
| Cooling system | |
| Coolant Capacity With Radiator: Thermostat: Max. Water Temperature: | 60.6 L 82-93ºC 104ºC |
| Alternator Parameter: Basic Information | |
| The alternators meet the standards of: GB755, BS5000, VDE00530, NEMAMG1-22,IED34-1,CSA22.2 and AS1350 | |
| Technical Data: | |
| Manufacturer: Phases: Connection: Bearing numbers: Power Factor: Protection Class: Altitude Condition: Excitation: Insulation class/Temp. rise class: Tel. Influence Factor TIF: Tel. Harmonic Factor THF: Steady State Voltage Regulation: Alternator Capacity: Efficiency: Cooling Air Flow: | Stamford HCI444ES 3 3 phase 4 wire, Y type 1 0.8 IP23 ≤1000M Brushless, self-excitation H / H <50 <2% ≤±1% 394KVA 93.7% 0.99 m³/s |
